H Clip for invisible connection of Rhombus facade profiles
- connection of Rhombus facade profiles without visible screw heads
- resistance to all weather conditions guaranteed due to special hardened PVC material and clips are safe in temperatures of -50/+50°C.
- Unified dilatation between facade boards
Specially designed H-clips allow faster and easier installation of wooden facades, allowing air circulation through regular gaps of 5 mm, thanks to the elevation of the facade boards above the substructure.
They provide independent installation of the wooden boards and in case of any problem that may occur in the wood, the damaged board can be easily replaced with a new one.
When installing the cladding, the H-clips automatically create consistent gaps between the boards.
The installation system offers an invisible connection as well as perfect structural protection for the wood.
H Clips are supplied in a box of 600 pieces. However, the sale is possible in pieces.
For the installation of 1 m2 of cladding, 30 Clips H are required for a Rhombus cladding profile of 92 mm width.
Clip H box contains 600 pcs; thus for installing 20m2 of cladding.
For the installation of 1 m2 of cladding, 30 Clips H are required for Rhombus 92 mm cladding profile.
For the connection of H Clip with underconstruction we recommend Hapatec screws made of C1 hardened stainless steel in the dimension 4x40mm.
